95000 USD
The RICH 10 – axle extendable trailer has been engineered to offer customers an unrivalled combination of efficiency and lightweight construction. It is a top – tier solution for transporting hefty loads, such as wind towers, with utmost reliability.
- SKU: 10 Axle Extendable Trailer
- GTIN: 6975766110642
- MPN: RICH9432004
- Brand: RICH
[Picture] [Quotation] [WhatsApp] [Add to cart]
The RICH 10 – axle extendable trailer showcases a state – of – the – art design. Its unique feature lies in the placement of three extensions at the front of the trailer. The adoption of a single – beam design is a masterstroke, as it substantially cuts down the weight of the telescopic beam, resulting in a significantly lighter trailer. This not only enhances fuel efficiency but also eases manoeuvrability.
- Dimension (LWH):
- Closed state: 18,500mm X 2,990mm X 950mm
- Extension state: 33,500mm X 2,990mm X 950mm
- Deadweight:
- Without ramps: 28.5 Ton
- With ramps: 29.5 Ton
- Frame: HG60 high – strength steel frame, ensuring durability and high – load capacity.
- Loading capacity: 90 Ton
- Length: 18,500mm in closed state; 33,500mm when fully extended
- Width: 2,990mm + 2 X 250mm side – swing bracket
- Height: 200mm+/-90mm
- Axle: 10 Axles
- Maximum steering angle: +/-25°
- Tyre: 40 units of 215/75R17.5
- Gooseneck: Hydraulic gooseneck for smooth height adjustment and better control.
- Suspension: Hydraulic lifting suspension, mainly for platform levelling.
- Hydraulic power station: 1 set with a 12Kw diesel engine.
- Loading Ramps: 1 set of detachable ramps.
- Landing gear: JOST C200
- Operation: Equipped with 2 wireless remote controls and 1 control valve panel for convenient operation.
- Load – bearing platform features: The load – bearing platform comes with 250mm wideners on both sides. Measuring 14.5m in length, it has a two – level tensile structure. This structure can stretch by 7500×2, allowing the freight platform to reach 29m after extension, catering to a wide range of load lengths.
- Powered gooseneck: The gooseneck is powered, featuring a mechanism for adjusting the cargo platform’s height and setting the axle’s steering part. This enables seamless operation and precise load handling.
- Advanced suspension system: The hydraulic suspension has a lifting function. It balances the force between axles via the suspension cylinder and also allows for independent axle lifting, ensuring stability and adaptability on different terrains.
- Axle and tyre configuration: With 10 axles, including 8 active – steering axles (4 in the front and 4 at the back), and 235/75R17.5 tyres, the trailer offers excellent manoeuvrability and load – distribution capabilities.
- Steering control: The active – steering axles are precisely controlled by hydraulic cylinders, providing accurate steering and enhanced safety during transportation.
Welcome to leave your inquiry! We will promptly furnish you with more details, price quotations, catalogues, drawings, and videos.
